Popis
Hydromotor CASAPPA KM 30.51 na vývevu:
MEC 9000/H
MEC 2000/H
MEC 3000/H
MEC 4000/H
MEC 5000/H
MEC 6500/H
MEC 8000/H
Especificaciones
– High operating pressure: – High efficiency at high temperatures – Solid and compact design |
|
Ventajas | – Long service life – Wide range of applications – Low space requirement |
Usos | – Mobile applications – Industrial applications |
Propiedades | – Low noise emission – Customer-specific design possible |
Unit | Each |
Connection | European 4-hole flange |
Material | Pump housing, flange and back cover: Steel |
Shaft type | Tapered shaft 1 : 8 |
Pressure (bar) | Pressure continuous (p1): 230 |
Flange type | E4, spacing ring 60,3 mm group 3. |
Note | Always connect leakage oil line |
A (mm) | 150 |
B (mm) | 91 |
D (mm) | 51 |
Direction of rotation | CW + CCW |
E (mm) | 51 |
P1 (bar) | 230 |
Suction flange | 3 G-16 |
Pressure flange | 3 G-16 |
N max. (Rpm) | 2500 |
N min. (Rpm) | 350 |
Q (cc/rev) | 51,83 |
Part no./
Reference no.
Pump type | Engine type | Flow rate max. (l/min) | Max. speed (rpm) | Working pressure max. (bar) | Pressure max. (bar) | |||
MEC2000/H MEC3000/H MEC4000/H MEC5000/H MEC6500/H MEC8000/H MEC9000/H |
KM 30.51-SO | 51,33 | 1200 | 55 75 105 125 160 185 230 |
